40 Pin PIC Terminal Development Board

40 Pin PIC Terminal Development Board

More details


31,40 € tax incl.

AC-SF-DEV-00027

Description: Want a serial LCD with some muscle? Maybe you just need a compact development board with a USB connection. This development board is what you've been looking for. The PIC-MT-USB uses a 40-Pin PIC at 20MHz, takes power from the USB port, communicates serially through the FTDI USB<->RS232 IC, interfaces directly to a backlit 2x16 character LCD, and leaves 16 general purpose IO pins for your wildest ideas.

Take a look at the example code for a quick start into using the USB-Serial connection for directly printing to the LCD screen.

  • FR-4, 1.5 mm (0.062"), green soldermask, white silkscreen component print
  • 20MHz crystal
  • LCD 16x2 alphanumeric display with backlight
  • 2 Buttons
  • Bi-color LED
  • Power supply taken from USB port
  • Virtual USB-RS232 port
  • ICSP/ICD connector for programming with PIC Programmers and Debuggers (for PICs with ICD support)
  • DIL40 microcontroller socket
  • Four mounting holes
  • Extension headers for PIC unused ports

Dimensions: 95x36mm (3.7x1.4")

Documents:

Drivers: This board uses the FT232BM from FTDI. Drivers are here.

Spark Fun MT-USB Example Code - Code to get you started with the LCD, buttons, internal EEPROM, etc.

Board does not come with PIC installed. Please see a list of related ICs below.
